Full Description
O2 gas analyser: suitable for modified atmosphere packaging (MAP)
The O2 LEGEND is a portable, reliable and durable gas analyser. This measurement device is ideal for starting small modified atmosphere packaging (MAP) productions or other inerting. The last measure on the screen will stay there until the next cycle is started.
THE + PRODUCTS
- Performance/Quality/Cost
- Reliability/Durability/Simplicity
- Low Sample volumes
- Runs off batteries (or from a power supply)
- Can be used for combined O2/CO2 gas analysis
Features
| Ingress protection of enclosure | IP 41 |
| Measurement device | Portable |
| Enclosure | Aluminium |
| Weight | 750 g |
| Width | 125 mm |
| Height | 50 mm |
| Depth | 180 mm |
| Battery | NiMH Battery. Battery autonomous up to 24h (or 6,000 measurements) when used continuously and intensively.100% charge in 4h |
| Power | 100-250VAC power supply via external charger – 50/60Hz |
| Display | 2 lines of 8 characters LCD |
| Storage conditions | 0 - 70°C/0 - 90% HR |
| Terms of use | 0 - 40°C/10 - 90% HR |
| O2 Oxygen measurement | Technology : Electrochemical Precision : +/- 1% relative T90 response time : |
