CAP1000 Viscometer
The CAP 1000+ Viscometer is a compact, heavy-duty instrument that is ideal for fast, easy, repetitive testing on the production floor or in the QC lab. Small sample size is a plus, along with integrated temperature control built into the sample plate.
Full Description
The CAP 1000+ Viscometer is a compact, heavy-duty instrument that is ideal for fast, easy, repetitive testing on the production floor or in the QC lab. Small sample size is a plus, along with integrated temperature control built into the sample plate.
FEATURES AND BENEFITS
- Quick single point test
- Choice of shear rate. Standard speeds include 750 and 900 rpm to provide shear rate at 10,000 sec-1.
- Rapid temperature control with built-in Peltier element in sample plate
- Meets Industry Standards: ASTM D4287, ISO 2884 and BS 3900
- Rugged design can handle production environment
- Small Sample Size, < 1 mL, Simplifies Testing
- Easy to Clean
- Customizable options
- Parallel printer output
LET US HELP YOU CONFIGURE THE CAP 1000+ TO PROVIDE A SIMPLE, SINGLE POINT, VISCOSITY TEST
- Specify one speed or shear rate if this is required for your method.
- Indicate viscosity range.
- Select the temperature range that best suits your application: 5°C to 75°C or 50°C to 235°C
- Choose from 10 spindles for multiple viscosity ranges
- Brookfield will help choose the appropriate instrument configuration.
