LD_100KN computer controlled universal testing machine

LD_100KN universal testing machine

LD_100KN universal testing machine is applicable in testing the rubber ,plastic film ,cable , fabric , paper ,aluminum board and so on . It is ideal for high-capacity tension, compression, bend/flex, and shear testing, these machines are guaranteed to meet the relative requirements of ISO, ASTM, JIN, GB and many other testing standards.

Main Technical Parameter

• Maximum test force 100kN
• Test force indication accuracy =±1%
• Test force measurement range Maximum test force 2%~100%
• Test force accuracy better than ±1%
• Displacement resolution 0.01mm
• Displacement measurement accuracy better than ±1%
• Test speed range 0.01-500mm/min
• Stretching space (excluding clamps) 600mm
• Compression space 600mm
• Column spacing 400mm
• The holding range of the wedge-shaped fixture 0-21mm for flat samples, F4-26mm for round samples
• Host size Refer to electronic universal testing machine for specific size
• The weight of the main unit Refer to electronic universal testing machine for specific size Motor power 0.75KW
• Power supply 220V, 50Hz
