C632B Hot Tack Tester

Packaging Testing Equipment

C632B Hot Tack Tester is applicable in hot tack and heat seal performance tests for plastic films, laminated films and other packaging materials. It is applicable in peel test, tensile at break test, and other tests for adhesives, adhesive tapes, laminated films, plastic films, paper and other…

Request Quote Download Datasheet

Ask a question →

Full Description

Product FeaturesNote1

Multiple Test Modes in One Instrument

Four test modes including hot tack, heat seal, peel and tensile test.
With Digital P.I.D. temperature control system, the preset temperature can be reached in a short time without fluctuations.
Four force test ranges and 6 testing speeds are available to meet various testing requirements
The instrument meets the requirement for testing speed specified in standard GB/T 34445-2017

Excellent Designs & Auto Sampling

Auto sampling for hot tack test, simplifies the testing operation and minimizes errors, ensures the uniformity of test data
Pneumatic sample clamping system (optional)
Automatic zeroing, error alert, overload protection and stroke protection guarantee safe operations
Instrument can be started manually or by pedal switch. it is convenient for the operator and the anti-scald design ensures safe operations
Components and parts of the instrument are supplied by world renowned manufacturers and have reliable performance

Computer & Instrument Controlled Operations

Test operations can be performed on the instrument or by the software
The instrument can be operated without a computer, easy to operate and view test data
Data I/O ports for data export

Applications

Basic Applications

Hot Tack Performance Plastic films, sheets and composite films e.g. PE, PP, PET and composite films used in packages for instant noodle, milk powder, washing powder, food and drugs

Heat Seal Performance Plastic films, sheets and composite films

Peel Strength Adhesives and adhesive tapes

Tensile Strength Tensile strength test of various films, sheets and composite films

Extended Applications

Medical Adhesives Peeling test and tensile strength test of medical adhesives e.g. adhesive bandages

Textiles, Nonwovens and Woven Bags Peeling test and tensile strength test

Adhesive Tapes Low speed unwrapping test

Protection Films Peeling test and tensile strength test

Magnetic Cards Peeling test of the films and magnetic cards

Bottle Caps Opening force test of the aluminum plastic combination bottle caps

Technical Specifications Note2

Specification	C632B Hot Tack Tester
Load Cell Capacity	30 N (Standard) 50 N 100 N 200 N (Optional)
Force Accuracy	Indicated Value ±1% (10%-100% of load cell capacity) ±0.1%FS (0%-10% of load cell capacity)
Force Resolution	0.01 N
Test Speed	150 200 300 500 hot tack 1500mm/min, 2000mm/min
Specimen Width	15 mm, 25 mm or 25.4 mm
Stroke	500 mm
Heat Seal Temperature	Room Temperature ~ 250°C
Temperature Variation	±0.2°C
Temperature Accuracy	±0.5°C (Single Point Calibration)
Dwell Time (Heat Seal Test)	0.1 ~ 999.9 s
Dwell Time (Hot Tack Test)	0.1 ~ 999.9 s
Sealing Pressure	0.05 Mpa ~ 0.7 MPa
Sealing Area	100 mm x 5 mm
Sealing Jaws	Double (one is silicon rubber)
Gas Supply	Air (Not in supply scope)
Gas Supply Pressure	0.7 Mpa (101.5psi)
Port Size	Φ4 mm PU Tubing
Instrument Dimension	1120 mm (L) × 380 mm (W) × 330 mm (H)
Power Supply	220VAC±10% 50Hz / 120VAC±10% 60Hz
Net Weight	45 kg
